Premium - Profile Signs

The high performing F 500E laminator offers a perfect application of the reflective films on aluminium or steel profiles.

In this type of of laminator, which is the first one in the new generation of laminators, the experiences from previous types have been gathered, and the innovations and present needs in the market have been brought up. The F 500E Laminator is provided with all the control and security devices for the application of reflective films on aluminium and steel profiles, from 150 mm. up to 350 mm. width.

Adjustable laminating width: 150 up to 350 mm.
Laminating thickness: 0 up to 30 mm.
Laminating speed: 0 up to 20 m/min.
Up / down movement of the pneumatic roll
Pneumatic apply of the reflective sheet reel
Automatic silicone rewinder

Length: 3000 mm.
Width: 1300 mm..
Height: 1850 mm.
Approximate weight: 950 Kg.
Electrical requirements: 220 V 50 Hz.
Power consumption: 12 Kw.
Safety CE
Working temperature: +16C up to +26C
